MOSFET / 场效应管
昭矽微电子提供各种高压/中低压MOSFET，以及各种肖特基二极管产品。
Promising Chip
LV MOSFET
HV MOSFET
Shottky
Trench MOSFET
SGT MOSFET
PLANAR MOSFET
SJ MOSFET
Low-VF-Shottky
类别：Promising Chip系列
| PartNumber | BVDSS(V) | ID(A) | RDS(ON) | Qg(nC) | Package | Type | Update |
|---|
10
| PC 7N100 | 1000(V) | 7(A) | 2.16(Ω) | / | / | Planar MOS | / |
| PC 4N100 | 1000(V) | 4(A) | 3.15(Ω) | / | / | Planar MOS | / |
| PC 6N90 | 900(V) | 6(A) | 1.8(Ω) | / | / | Planar MOS | / |
| PC 10N80 | 800(V) | 10(A) | 1.0(Ω) | / | / | Planar MOS | / |
| PC 7N80 | 800(V) | 7(A) | 1.5(Ω) | / | / | Planar MOS | / |
| PC 7N100 | 1000(V) | 7(A) | 2.16(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 4N100 | 1000(V) | 4(A) | 3.15(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 20N65 | 650(V) | 20(A) | 0.41(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 12N65 | 650(V) | 12(A) | 0.62(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 7N65 | 650(V) | 7(A) | 1.05(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 5N65 | 650(V) | 5(A) | 1.80(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 4N65 | 650(V) | 4(A) | 2.79(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 2N65 | 650(V) | 2(A) | 3.87(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 1N65 | 650(V) | 1(A) | 7.38(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 08N65 | 650(V) | 0.8(A) | 12.6(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 20N60 | 600(V) | 20(A) | 0.36(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 12N60 | 600(V) | 12(A) | 0.55(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 7N60 | 600(V) | 7(A) | 0.89(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 5N60 | 600(V) | 5(A) | 1.62(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 4N60 | 600(V) | 4(A) | 2.61(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 2N60 | 600(V) | 2(A) | 3.42(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 1N60 | 600(V) | 1(A) | 6.30(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 08N60 | 600(V) | 0.8(A) | 10.80(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 05N60 | 600(V) | 0.5(A) | 34.20(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 20N55 | 550(V) | 20(A) | 0.26(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 12N55 | 550(V) | 12(A) | 0.52(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 7N55 | 550(V) | 7(A) | 0.81(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 2N55 | 550(V) | 2(A) | 5.40(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 20N50 | 500(V) | 20(A) | 0.24(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 12N50 | 500(V) | 12(A) | 0.36(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 7N50 | 500(V) | 7(A) | 0.59(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 5N50 | 500(V) | 5(A) | 1.17(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 4N50 | 500(V) | 4(A) | 1.94(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 3N50 | 500(V) | 3(A) | 2.43(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 2N50 | 500(V) | 2(A) | 4.95(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 1N50 | 500(V) | 1(A) | 7.90(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 05N50 | 500(V) | 0.5(A) | 24.30(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC N | 100(V) | 120(A) | 0.004(Ω) | / | / | SGT MOS | / |
| PC N | 100(V) | 70(A) | 0.009(Ω) | / | / | SGT MOS | / |
| PC N | 80(V) | 120(A) | 0.006(Ω) | / | / | SGT MOS | / |
| PC N | 80(V) | 50(A) | 0.015(Ω) | / | / | SGT MOS | / |
| PC 100N15 | 150(V) | 100(A) | 0.009(Ω) | / | / | Trench MOS | / |
| PC 50 N12 | 120(V) | 50(A) | 0.016(Ω) | / | / | Trench MOS | / |
| PC 120N10 | 100(V) | 120(A) | 0.027(Ω) | / | / | Trench MOS | / |
| PC9 N10 | 100(V) | 9(A) | 0.150(Ω) | / | / | Trench MOS | / |
| PC 3N10 | 100(V) | 3(A) | 0.240(Ω) | / | / | Trench MOS | / |
| PC 1N10 | 100(V) | 1(A) | 0.510(Ω) | / | / | Trench MOS | / |
| PC 120N08 | 80(V) | 120(A) | 0.004(Ω) | / | / | Trench MOS | / |
| PC 110N08 | 80(V) | 110(A) | 0.005(Ω) | / | / | Trench MOS | / |
| PC 75N75 | 75(V) | 75(A) | 0.011(Ω) | / | / | Trench MOS | / |
| PC 80N04 | 40(V) | 80(A) | 0.008(Ω) | / | / | Trench MOS | / |
| PC 60N04 | 40(V) | 60(A) | 0.031(Ω) | / | / | Trench MOS | / |
| PC 6N03 | 30(V) | 6(A) | 0.035(Ω) | / | / | Trench MOS | / |
| PC 2N40 | 400(V) | 2(A) | 3.38(Ω) | / | / | Planar MOS | 2018-09-31 |
| PC 4N03 | 30(V) | 4(A) | 0.051(Ω) | / | / | Trench MOS | / |
